Products Description
Geomembranes, also known as geosynthetic membranes, are essential components in various industries, including waste containment, water management, aquaculture, energy, mining, and civil engineering. They provide reliable barriers against liquid and gas migration, ensuring environmental protection and resource conservation.
| Name; geomembrane |
| Length; 1-6m |
| Thickness; 0.3 -2 mm |
| Material; HDPE, LDPE, PVC, LLDPE |
| Color; Black, white, blue, customized products can be supported according to customer needs |
Material and Production:
Our geomembranes are manufactured from high-grade polyethylene raw materials, enhanced with carbon black, antioxidants, and UV-resistant additives. Utilizing state-of-the-art automated production lines and advanced pressing technology, we guarantee superior quality and durability.
Properties | Test Method | GMSH050 | GMSH075 | GMSH100 | GMSH150 | GMSH200 |
■ Thickness | ASTM D5199 | 0.50 mm | 0.75 mm | 1.00 mm | 1.50 mm | 2.00 mm |
■ Density | ASTM D1505 | 0.940 g/cc | 0.940 g/cc | 0.940 g/cc | 0.940 g/cc | 0.940 g/cc |
Tensile Properties | ||||||
■ Yield strength ■ Break strength ■ Yield elongation ■ Break elongation | ASTM D6693 Type IV
| 7 kN/m 13 kN/m 12% 700% | 11 kN/m 20 kN/m 12% 700% | 15 kN/m 27 kN/m 12% 700% | 22 kN/m 40 kN/m 12% 700% | 29 kN/m 53 kN/m 12% 700% |
■ Tear Resistance | ASTM D1004 | 62 N | 93 N | 125 N | 187 N | 249 N |
■ Puncture Resistance | ASTM D4833 | 160 N | 240 N | 320 N | 480 N | 640 N |
■ Stress Crack Resistance | ASTM D5397 | 500 hrs | 500 hrs | 500 hrs | 500 hrs | 500 hrs |
■ Carbon Black Content | ASTM D1603 | 2.0% | 2.0% | 2.0% | 2.0% | 2.0% |
■ Carbon Black Dispersion | ASTM D5596 | For 10 different views:9 in Categories 1 or 2 and 1 in Category 3 | ||||
■ Oxidative Induction Time (OIT) | ASTM D3895 | 100 min. | 100 min. | 100 min. | 100 min. | 100 min. |
■ UV Resistance High Pressure OIT retained after 1600hrs |
ASTM D5885 |
50% |
50% |
50% |
50% |
50% |
Dimensions | ||||||
■ Roll Width (m) | 7 | 7 | 7 | 7 | 7 | |
■ Roll Length (m) | 420 | 280 | 210 | 140 | 105 | |
Product Range:
Smooth Geomembrane: Available in three colors—black, white, and green—ideal for a variety of applications, from lining ponds to landfill caps.
Textured Geomembrane HDPE Liner: Designed with single or double-sided textures to enhance friction and stability, perfect for steep slopes and erosion control.
Composite Geomembrane Liner: Combines the benefits of different materials for added strength and versatility, suitable for complex engineering projects.
Customization Options:
We offer ODM and OEM services, allowing for tailored solutions to meet your specific project requirements. Whether you need unique dimensions, colors, or additional features, we can accommodate your needs.
Applications:
Waste containment (landfills, hazardous materials)
Water containment (ponds, reservoirs, canals)
Aquaculture (fish and shrimp farming)
Mining (tailings, leach pads)
Civil engineering (subway linings, underground structures)
Conclusion:
Choose our geomembranes for their proven performance and reliability in diverse applications. With customization options available, we are dedicated to providing solutions that meet the highest standards of quality and environmental safety.
